Digitus cat 6 modular wall outlet (A1)

Digitus cat6-seinäpistorasia on pinta-asennettava ja  sisältää 2 suojattua RJ45 naaras liitäntää. Paras teho ja yhteys laatu verkkollesi.

Pinta-asennus muotoilu ja vaakatasossa oleva kaapelin sisääntulo mahdollistaa siistijn ja helpon asennuksen.

Turvallisuus on varmistettu täysin suojatun rj45 kannan ja LSA liuskan ansiosta.

Kannat ovat 40° kulmassa joka mahdollistaa kaapelien helpon liittämisen.

tekniset tiedot

Transmission property: Category 6
Area of application: Up to 250 MHz, 1GBase-T
Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C
Suitable for installation in trunking,
surface and flush mount
RJ45 female, 8P8C
Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B
Integrated strain relief for installation cables
Complete shielding of RJ45 sockets and LSA strips due to zinc die-cast housing
Strain relief 40°-angled female for patch cord
Central plate: 50 x 50 mm
Frame: 80 x 80 mm
Central plate with integrated dust covers
Design compatible to common switch ranges
Technical properties:
Housing material: Die-cast metal
RJ45 female material: ABS UL 94V-0
RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact
RJ45 shielding: Tinned bronze
LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze
Conductor plate: FR4, UL 94V-0
Physical properties:
Insertion force: 30N max. (IEC 60603-7-5)
Retention strength: 7.7 kg between jack and plug
Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5
Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5
IDC wire size: 22 – 26 AWG solid and stranded conductor
Insulation resistance: > 500 MOhm
Contact resistance: < 20 MilliOhm
Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
